Digi Embedded

Digi Antennas

Digi offers various anteannas (2.4 Ghz, Wi-Fi, RPSMA, etc.) to fit your requirements

DIGI CONNECT ME

Secure device server module with plug-and-play functionality and professional evelopment tools for custom applications The Digi Connect ME is a secure device server module that delivers complete and versatile embedded IPv6-ready network connectivity and strong standards-based encryption services such as SSL/SSH. Built on leading Digi 32-bit NET+ARM technology, the Digi Connect ME is cost effective and easy to use in existing and new product designs, while powerful enough to meet future product performance needs. The connector-style module is pin-compatible and interchangeable with the Digi Connect® Wi-ME, providing a direct migration path to a wireless solution without the traditional complexities of hardware and software integration work. Digi Connect ME is available pre-loaded with Digi plug-andplay firmware, which eliminates software development efforts by providing powerful and configurable IPv4/IPv6 device server functionality, including an easy-to-use web user interface and security features. Target applications include retail systems, security/access control, medical devices and building/industrial automation.

Features

- Compact and secure 32-bit device server modules - Complete family of pin-compatible module solutions - Integrated 10/100 Mbit Ethernet interface - Strong enterprise-grade network security - Highly integrated low emission design (FCC Class B) - Extended and industrial operating temperature - Digi processor and WLAN technology for true long-term availability

DIGI CONNECT ME 9210

Ultra-compact high-performance embedded modules for M2M networking combine on-chip security The Digi Connect ME 9210 embedded module enables secure wired and wireless networking. Built on Digi’s powerful NS9210 ARM9 processor, the high-performance module allows customers to implement next generation network-enabled products. Additionally, the RJ-45 form factor is pin compatible with modules in the Digi Connect ME family. The module can provide future application-specific interface options through the programmable Flexible Interface Module (FIM), while keeping the main serial port or other key peripheral interfaces available. It is well-suited for more advanced core module applications by supporting up to ten shared GPIOs, external IRQs and an extended set of peripheral interface options. The Digi Connect ME 9210 features the development and operational benefits of Digi Remote Manager ®. This secure, highly-scalable platform seamlessly ties enterprise applications and remote devices together. Using Digi Remote Manager, customers can also easily configure, upgrade, monitor and troubleshoot their device from a centralized location.

Features

- Integrated 10/100 Mbit Ethernet interface - Support for Digi Embedded Linux and Digi NET+OS - Industrial operating temperature System-on-Module - RJ-45 form factor compatible with Digi Connect ME - On-chip hardware encryption engine - Extended set of on-chip interfaces and signals - Power management modes - Low-emission design (FCC Class B)

Digi Connect ME 9210 Digi JumpStart Kit

for Digi Embedded Linux, w/Eclipse-based Digi ESP IDE, LiveDVD, and installation and setup support package What's in the box: Quick start guide Digi Connect ME module w/JTAG - 75 MHz NS9210, 4 MB Flash, 8 MB SDRAM Digi JumpStart Kit development board - RS-232 serial port, GPIO screw terminal, test points, application connectors, prototyping area, RS-232 console port (JTAG), 9-30VDC power supply Digi Embedded Linux DVD - Digi Embedded Linux, Digi ESP IDE, source code, boot loader source code, sample code Documentation and development board schematics Power supply and accessories - External wall power supply with adapters, Ethernet cable, serial cable

DIGI CONNECTCARD FOR i.MX28

Cost-effective small-footprint System-on-Module solution delivers performance, lowpower operation and integrated 802.11a/b/g/n, Bluetooth 4.0 and Ethernet connectivity Based on the NXP i.MX28 processor family, the ConnectCard for i.MX28 is an ideal embedded platform solution for connected applications in medical and healthcare, energy, transportation and industrial/building automation. It offers easy design integration and unique peripheral/ interface flexibility in an extremely compact and cost-effective form factor. This module is suitable for a wide range of different devices, including battery powered product designs. The module is equipped with a highly integrated 32-bit ARM core running at up to 454 MHz, on-chip power management, dual Ethernet and 802.11a/b/g/n networking options, Bluetooth 4.0 connectivity, dual FlexCAN options, GPIO, ADC, UART, USB high-speed, SPI, I2C, I2S, 1-Wire, PWM and JTAG/ETM. The Digi JumpStart Kit® for Digi Embedded Linux provides a complete turnkey embedded development solution allowing immediate and successful product development with accelerated time-to-market and reduced design risk.

Features

- Cost-effective design in compact form factor - 32-bit ARM processor at up to 454 MHz - Single/dual 10/100 Ethernet connectivity options - Pre-approved 802.11a/b/g/n Wi-Fi + Bluetooth 4.0 - Includes Wi-Fi® Access Point mode + Wi-Fi Direct™ - Support for Bluetooth 3.0 + HS and Bluetooth LE - Ready for Cisco CCX and Wi-Fi Logo certification - Digi Embedded Linux platform - Digi Remote Manager ® enabled - Includes complete Digi BSP source code - Long-term product availability - Additional ZigBee®, 802.15.4, cellular and satellite connectivity options (off-module)

DIGI CONNECTCORE 6 JUMPSTART DEV KIT

The ConnectCore® 6 Single Board Computer on which it is based is an ultra-compact and highly integrated system-on-module solution based on the NXP i.MX6 Cortex-A9 processor family. With processor speeds up to 1.2 GHz and fully pin-compatible single-/dual-/quad-core variants, the ConnectCore 6 offers a truly future-proof platform solution with scalable performance and pre-certified wireless 802.11 a/b/g/n and Bluetooth 4.0, including Bluetooth Low Energy, connectivity. Its low-profile, surface-mount design maximizes integration flexibility and significantly reduces design risk in a highly cost-effective, reliable form factor with optimized heat dissipation capabilities even in the most demanding quadcore system configurations. The ConnectCore 6 comes with a complete Board Support Package (BSP) for both Linux and Android platforms supporting secure remote management and web services through Digi Remote Manager ®

Features

Digi CC6 Dev Kit Includes: - SBC with ConnectCore 6 module (i.MX6Quad, 1.2 GHz), 4GB flash, 1GB DDR3, 802.11a/b/g/n, Bluetooth 4.0, and Kinetis Microcontroller Assist. - Software for Yocto Linux and Android development - Quick Start Guide - Power supply - Cable accessories

Overview coming soon - Call 01527 830800 for information

DIGI CONNECTCORE 6+

NXP i.MX6Plus based surface-mount module solution with scalable, quad-core performance and integrated wireless The Digi ConnectCore® 6+ is an ultra-compact and highly integrated system-on-module solution based on the NXP i.MX6Plus Cortex-A9 processor family. With processor speeds up to 1.2 GHz and fully pin-compatible dual-/quad-core variants, the ConnectCore 6+ offers a truly future-proof platform solution with scalable performance and pre-certified wireless 802.11a/b/g/n/ac and Bluetooth 5, including Bluetooth Low Energy, connectivity. Its low-profile, surface-mount design maximizes integration flexibility and significantly reduces design risk in a highly cost effective, reliable form factor with optimized heat dissipation capabilities even in the most demanding quad-core system configurations. Integrated cloud integration as part of the Digi Yocto Linux and Android software platform support offers secure remote management and web services capabilities through the scalable Digi Remote Manager®.

Features

- Scalable Cortex-A9 multi-core performance - Independent Cortex-M0+/Cortex-M4 Microcontroller Assist™ subsystem - Cost-effective, reliable, low-profile surface-mount module form factor - Pre-certified 802.11a/b/g/n/ac and Bluetooth 5 - Smart Power Management Architecture with PMIC - Android and Yocto Project Linux software platform support - Reliable design with IEC 60068 and HALT verification - Dedicated on-module security + authentication controller - Designed for long-term availability

DIGI CONNECTCORE 6 SBC

Reliable and compact NXP i.MX6 SBC family with integrated Ethernet, Wi-Fi, Bluetooth 4.0, Digi XBee and cellular connectivity options Digi ConnectCore® 6 SBC is an ultra-compact and versatile off-the-shelf single board computer (SBC) family. It offers significantly reduced time to market by virtually eliminating the traditional risk, effort and complexity of custom board designs without sacrificing flexibility or capabilities. Built on the ConnectCore 6 module, it provides a common platform with scalable NXP i.MX6 performance, precertified Bluetooth® 4.0 and Wi-Fi integration, Digi XBee® RF module and cellular connectivity options, Gigabit Ethernet support, multi display/camera and audio support, external storage, expansion connectors, and reliability in harsh environments. Leading and innovative features such as Digi Microcontroller Assist™ (MCA) enable the development of connected products with highly optimized power footprints. Optional Digi Remote Manager® integration provides secure remote management and device health capabilities for the Internet of Things.

Features

- Compact off-the-shelf SBC family - Scalable capabilities and i.MX6Quad/Dual/DualLite performance - Gigabit Ethernet and pre-certified dual-band Wi-Fi + Bluetooth 4.0 - Ready for cellular connectivity and Digi XBee RF - Complete set of available peripherals and interfaces with customization options - Designed for flexibility and reliability - Windows® Embedded Compact, Yocto Project® Linux® and Android software platform support - Industrial operating temperature available

DIGI CONNECTCORE 6

NXP i.MX6 based surface-mount module solution with scalable, single-/multi-core performance and integrated wireless The ConnectCore® 6 is an ultra-compact and highly integrated system-on-module solution based on the NXP i.MX6 Cortex-A9 processor family. With processor speeds up to 1.2 GHz and fully pin-compatible single-/dual-/quad-core variants, the ConnectCore 6 offers a truly future-proof platform solution with scalable performance and pre-certified wireless 802.11 a/b/g/n and Bluetooth 4.0, including Bluetooth Low Energy, connectivity. Its low-profile, surface-mount design maximizes integration flexibility and significantly reduces design risk in a highly cost-effective, reliable form factor with optimized heat dissipation capabilities even in the most demanding quadcore system configurations. The ConnectCore 6 comes with a complete Board Support Package (BSP) for both Linux and Android platforms supporting secure remote management and web services through Digi Remote Manager

Features

- Scalable Cortex-A9 multi-core performance - Independent Cortex-M0+/Cortex-M4 Microcontroller Assist subsystem - Cost-effective, reliable, low-profile surface-mount module form factor - Pre-certified 802.11a/b/g/n and Bluetooth 4.0 - Smart Power Management Architecture with PMIC - Android, Yocto Project Linux and Windows Embedded Compact software platform support - Reliable design with IEC 60068 and HALT verification - Designed for long-term availability

Digi ConnectCore 6UL Development Kit

The Kit Includes. -3 Digi ConnectCore® 6UL SBC Pro with dual Ethernet, 802.11a/b/g/n/ac and Bluetooth® 5 -3 Console port cable -3 Dual-band antenna -3 Power supply and accessories Design and build your connected products on an industrial and productization-ready Single Board Computer platform The Digi ConnectCore® 6UL Development Kit delivers a complete offthe-shelf Single Board Computer (SBC) built on the ConnectCore 6UL System-on-Module (SOM). The SBC is a proven reference design for ConnectCore 6UL modulebased development, suited for rapid prototyping; as a productizationready product platform, it requires little to no hardware development effort. Its standard form factor is the ideal solution for connected applications demanding professional reliability and flexibility in medical/healthcare, transportation, energy, utility, agriculture, building automation and industrial markets. FOCUS ON YOUR CORE COMPETENCY The SBC is built on the ConnectCore 6UL SOM with a low-power NXP i.MX6UL application processor, 256 MB flash, 256 MB RAM, dual 10/100 Mbit Ethernet, pre-certified dual-band 802.11ac wireless LAN, Bluetooth® 5 connectivity, NFC tag capabilities, and complete set of available peripherals. Digi tests, integrates and maintains complete Yocto Project Linux BSP and software support for the ConnectCore 6UL module and SBC platform. This includes software components such as the Digi TrustFence® Device Security Framework, wireless connectivity stacks, and drivers for relevant industry leading cellular modems. We also offer optional services, including antenna design/selection guidance, cellular integration support, certification assistance, or custom design services, to get you to market faster and smarter.

Features

- Compact Pico-ITX form factor (100 mm x 72 mm) - NXP i.MX6UL with 256 K/1 GB NAND flash, 256 K/1 GB DDR3 - Pre-certified dual-band 802.11ac Wi-Fi connectivity - Bluetooth 5, with Bluetooth Low Energy support - NFC Forum Type 2 Tag compliant capabilities - Dual-10/100 Mbit Ethernet networking - Ready for cellular connectivity and Digi XBee® RF integration - Full and customizable set of peripherals and interfaces - Off-the-shelf and productization-ready SBC platform - Industrial operating temperature range - Complete Yocto Project® Linux® BSP with source code

Specifications

CC-WMX-JN58-NE	i.MX6UL-2, 528 MHz, Industrial Temp,  256 MB SLC NAND, 256 MB DDR3, Dual 10/100 Ethernet, 802.11a/b/g/n/ac, Bluetooth 4.1
CC-MX-JN58-Z1	i.MX6UL-2, 528 MHz, Industrial Temp, 256 MB SLC NAND, 256 MB DDR3, Dual 10/100 Ethernet
CC-WMX6UL-START	ConnectCore for i.MX6UL Starter Board, 87 x 63 mm, Industrial temp, 256 MB SLC NAND, 256 MB DDR3, single 10/100 Ethernet, 802.11a/b/g/n/ac, Bluetooth 4.2, PCB antenna, USB , UART, microSD, Pi HAT and Grove connectors, power (USB + header), and accessories
CC-WMX6UL-KIT	ConnectCore for i.MX6UL SBC, Pico-ITX (100 x 72 mm), Industrial Temp, 256 MB SLC NAND, 256 MB DDR3, Dual 10/100 Ethernet, 802.11a/b/g/n/ac, Bluetooth 4.2, XBee socket, cellular connectivity support via PCI Express Mini Card, SIM, NFC, microSD, USB Host, USB OTG, UART, DualCAN, SPI, I2C, LVDS, camera, antenna connector, battery connector, power supply, and accessories

DIGI CONNECTCORE 6UL SBC PRO

Secure and pre-certified Single Board Computer for total design flexibility and connectivity in industrial applications Digi ConnectCore® 6UL SBC Pro delivers the ultimate connected off-the-shelf NXP i.MX6UL single board computer in standard form factor for unparalleled design flexibility. Its unique pre-certified wireless connectivity options offer 802.11a/b/g/n/ac Wi-Fi and Bluetooth® 5, including Bluetooth Low Energy. Out-of-box cellular integration options using the pre-certified Digi XBee® Cellular module or third-party PCI Express Mini Card modem allows you to integrate cellular connectivity with less cost and complexity. Digi Linux® support includes TrustFence® device security framework with secure boot, encrypted file systems, protected ports and more.

Features

FEATURES AND BENEFITS - Powerful and flexible off-the-shelf solution in - Pico-ITX form factor - Production-ready with minimal hardware design effort - Rugged design with industrial operating temperature range - Pre-certified dual-band 802.11ac Wi-Fi connectivity - Bluetooth 5, with Bluetooth Low Energy support - Out-of-box support for cellular connectivity - On-board NFC Forum Type 2 compliant tag - Dual 10/100 Mbit Ethernet networking - Integrated display and camera capabilities - Rich interface and peripheral support - Complete Yocto Project® Linux BSP with source code - Digi TrustFence® device security framework

DIGI CONNECTCORE 6UL

Intelligent and connected embedded system-on-module based on the NXP i.MX6 UL, with turnkey Linux software support in a stamp-sized form factor The ConnectCore 6UL module delivers a secure and extremely cost-effective connected System-on-Module platform that is slightly bigger than a postage stamp. Its patent-pending Digi SMTplus surface mount form factor allows you to choose simplified design integration leveraging proven and easy-to-use edge-castellated SMT technology, or a versatile LGA option for ultimate design flexibility with access to virtually all interfaces. Built on the NXP i.MX6UL application processor, the module is the intelligent communication engine for today’s secure connected devices. It seamlessly integrates dual-Ethernet and pre-certified dual-band Wi-Fi (802.11a/b/g/n/ac) with Bluetooth 5 connectivity. Embedded device security is a critical design aspect for the growing number of connected applications (IoT) and the ConnectCore 6UL removes the implementation barriers by providing you with a fully integrated, secure module platform with complete Linux software support.

Features

FEATURES & BENEFITS - Secure, connected, highly cost-effective system-on-module - NXP i.MX6UL-2, Cortex-A7 @ 528 MHz - 256MB/1GB NAND flash, 256MB/1GB DDR3 - Stamp-sized and flexible Digi SMTplus form factor - Pre-certified 802.11a/b/g/n/ac + Bluetooth 5 option - Integrated dual 10/100 Ethernet connectivity - Dedicated on-module security + authentication controller - Unique ultra-low power and wake-up state management - Turnkey embedded Linux software platform with DigiTrustFence® embedded device security framework - Long-term availability and 5-year warranty

DIGI CONNECTCORE 8X SBC PRO DEVELOPMENT KIT

Design and build your connected products on an industrial and productization-ready single board computer platform The Digi ConnectCore® 8X SBC Pro development kit delivers a powerful, secure and cost-effective single board computer with complete support for Linux and Android. Digi ConnectCore 8X SBC Pro development kit reduces timeto-market by virtually eliminating the traditional risk, effort and complexity of custom board designs without sacrificing flexibility or capabilities. VERSATILE CONNECTIVITY ACROSS INDUSTRIES Streamline the process to design, build, test and deploy secure, industrial-ready products with the Digi ConnectCore 8X SBC Pro development kit. A range of applications support healthcare, transportation, energy, utility, agricultural, building automation and other industrial markets. The compact form factor integrates an on-board dualband antenna option, USB connectivity and Digi XBee® RF connector. Additional features include cellular connectivity options, multi-display/camera and audio support, external storage and expansion connectors. Digi also offers optional services including cellular integration support, certification assistance and custom design services to get your product to market faster and smarter.

Features

THE KIT INCLUDES: - Digi ConnectCore® 8X SBC Pro with dual-ethernet, 802.11a/b/g/n/ac and Bluetooth 5 - Console port cable - Two dual-band antennas - Power supply and accessories FEATURES AND BENEFITS - Industrial i.MX 8X quad-core SOM and SBC platform family - Compact Pico-ITX form factor (100 mm x 72 mm) - Power management with both hardware and software support for low-power designs - Multi-display and camera capabilities with hardware acceleration - Pre-certified dual-band 802.11a/b/g/n/ac 2x2 and Bluetooth 5 connectivity - Seamless cellular modem and Digi XBee3® integration - Cloud and edge compute services integration - Built-in Digi TrustFence® device security - Yocto Project Linux and Android support

Digi ConnectCore 8X SBC Pro

Design and build your connected products on an industrial and productization-ready single board computer platform Streamline the process to design, build, test and deploy secure, industrial-ready products with the Digi ConnectCore 8X Single Board ComputerPro. A range of applications support healthcare, transportation, energy, utility, agricultural, building automation and other industrial markets. The compact form factor integrates an on-board dualband antenna option, USB connectivity and Digi XBee® RF connector. Additional features include cellular connectivity options, multi-display/camera and audio support, external storage and expansion connectors. Digi also offers optional services including cellular integration support, certification assistance and custom design services to get your product to market faster and smarter.

Features

FEATURES - i.MX8QuadXPlus - 1.2 Ghz - -40º C to 85º C (-40º F to 185º F) - 16 GB flash - 2 GB LPDDR4, - 802.11a/b/g/n/ac 2x2 - Bluetooth® 5 - Dual Gigabit Ethernet

Digi ConnectCore 8X SOM

Main Features - Digi ConnectCore® 8X SOM QuadXPlus 1.2 GHz - 16 GB eMMC - 2 GB LPDDR4 - -40º C to 85º C (-40º F to 185º F) - 802.11a/b/g/n/ac 2x2 - Bluetooth® 5 Datasheet coming soon!

DIGI CONNECTCOREi.MX51 / Wi-i.MX51

High-end Cortex-A8 System-on-Module solution delivers industry-leading performance, low-power operation, and fully integrated 802.11a/b/g/n + Ethernet networking The network-enabled ConnectCore for i.MX51 family offers a highly integrated and future-proof System-on-Module (SOM) solution based on the new Freescale® i.MX515 application processor, which offers a high-performance ARM® Cortex™-A8 core, powerful multimedia options, and on-chip peripherals. The modules combine the fast integration, reliability and design flexibility of an off-the-shelf SOM with complete out-ofthe-box software development support for platforms such as Microsoft® Windows® Embedded CE 6.0, Windows Compact 7 and Digi® Embedded Linux. With industry-leading performance and key features such as a dual-display interface and a hardware encryption engine, the module is the ideal choice for a broad range of target markets including medical, digital signage, security/access control, retail, industrial/building automation, transportation and more.

Features

- High-end, low-power 32-bit System-on-Modules - Integrated 10/100 Mbit Ethernet networking - Pre-certified 802.11a/b/g/n wireless LAN interface - On-chip hardware encryption engine - Hardware accelerated high-definition multimedia - Power Management IC - Industrial operating temperature available - Low-emission design with FCC Class B compliance - ZigBee®, cellular and satellite connectivity options - Windows Embedded and Linux support
