Antenna - 2G/3G Cellular

2J CELLULAR Ultra Wideband Antenna Key Features: - Connector Mount - Hinged Connector - Low Profile - 2G/ 3G - Frequency: 824-960 MHz & 1710-2170 Mhz Radiation Pattern: Omni-Directional Applications where this Antenna is found are within Telematics. As these Antenna's offer efficient GPS and cellular solutions. Used in fleet management, tracking, transportation and IoT applications etc.

2G/3G Cellular High Performance Rigid Fiberglass Embedded Antenna Key Features: - High Performance - Customizable Cable and Connector - Rigid Embedded Antenna - Self-Adhesive - Ground Plane Independent Applications: Embedded Standards: 2G and 3G Frequency: 824-960, 1710-2170MHz Dimensions: 75 x 25 x 0.8 mm

CELLULAR 2G and 3G Flexible ultra-thin PCB Adhesive Antenna Key Features: - Customizable Cable and Connector - Self-Adhesive - Flexi Embedded Antenna - Flexible Material Applications: Embedded Standards: 2G and 3G Frequency: 824-960, 1710-2170MHz Dimensions: 70.4 x 26.4 x 0.1mm Connector Type: Most RF Connectors (U.FL Standard) Cable Length: Any Cable Length (100mm Standard) Cable Type: Other Cables Available (1.37mm Standard)

CELLULAR Flexible ultra-thin PCB Adhesive Antenna Key Features: - Self-Adhesive - Flexible Material - Ground Plane Independent - Customizable Cable and Connector Dimensions 74.9 x 8.1 x 0.1 mm Standards: 2G and 3G Frequency: 824-960, 1710-2170MHz Applications: Embedded

Cellular High Performance Rigid Customizable Antenna Key Features: - High Performance - Ground Plane Independent - Customizable Cable and Connector - Rigid Embedded Antenna - Self-Adhesive Applications: Embedded Standards: 2G and 3G Frequency: 824-960, 1710-2170MHz Dimensions: 75 x 8.1 x 0.8 mm

CELLULAR Rigid Fiberglass Antenna Key Features: - Embedded Antenna - Self-Adhesive - High Performance - Ground Plane Independent - Dimensions: 35 x 6.5 x 1.8 mm - Customizable Cable and Connector Frequency Ranges: - 824-960 MHz - 1710-2170 MHz Connector Type: Most RF Connectors (U.FL Standard) Cable Length : Any Cable Length (100mm Standard) Cable Type: Other Cables Available (1.37mm Standard)

Cellular Low Profile Right Angle Smart Antenna Key features of this Antenna include; Connector Mount, Low Profile, Ground Plane Dependent and a Right-Angle Connector. With a frequency range of 824-960, 1710-2170 MHz. The cellular standards of this Antenna are 2G and 3G, best suiting applications that are Telematic.

Cellular Omni-Directional Low Profile Ground Plane Dependent Antenna Key Features of this Antenna include; Connector Mount, Low profile and Ground Plane Dependent. This Antenna is both 2G and 3G, proving ideal for applications that are Telematic. Frequency : 824-960, 1710-2170 MHz Operating Temperature : -40 °C to +85 °C

4G LTE/3G/2G Ultra Wideband 90 Degree Connector Antenna The 2JW0124 series is an ultra wideband performance connector mount antenna solution for worldwide cellular applications operating within the 4G,3G and 2G standards. Key Features of this Antenna include: High Performance, Connector Mount, Easy Integration, Ultra Wide band Antenna and Hinged Connector. With different colours also available in this range upon request. Applications that are best suited for this Antenna are Telematic and LTE. Including Dash Cameras, Gateways, Routers, Connected cars etc. Frequency: 698-960, 1710-2170, 2500-2700 Operating Temperature: -40 °C to +85 °C
