Winmate – R17IB7T-IPM1 17″ Intel® Celeron® N2930 Front IP65 Panel PC

Product Overview

17″ TFT SXGA LCD
Intel® Celeron® Bay Trial-M N2930 1.83 GHz Processor
SO-DIMM DDR3L 1600, max. 8 GB
Integrated VGA, 24 bit Dual-channel LVDS, DVI
Integrated Dual Broadcom I210AT GbE Controller
1 x SATA II, 3 x COM, 3 x USB 2.0, 1 x USB 3.0, 2 x Mini PCIe slot Data

Features

Size

17 inches

Touch / Glass

Resistive Touch Screen
Protection Glass Without Touch Function (Optional)

Resolution

1280×1024

Panel Brightness

350 nits

Contrast Ratio

1000:1

View Angles

85,85,80,80

Active Area

337.920×270.336 mm

System Specification
Processor

Intel® Celeron® N2930 (2M Cache, up to 2.16 GHz)

Memory

2 x SO-DIMM, DDR3L 1600 MHz, 4GB
8GB (Optional)

Storage

1 x mSATA SSD 64GB
mSATA SSD up to 512GB (Optional)
1 x SATA II for 2.5″ HDD (Optional)

Ethernet controller

2 x Intel® Ethernet Controller I210-AT

Operating System

Windows 7 Embedded Systems (Optional)
Windows 10 IoT Enterprise (Optional)
Linux Ubuntu 18.04 (Optional)

WLAN

Support (Optional)

BT

Support (Optional)

Mechanical
Dimension

440 x 360 x 90 mm

Cut out

394x314mm

Mounting

Panel mount
VESA Mount

Enclosure

Metal Housing

Cooling System

Fanless design

Environment
Operating Humidity

10% to 90% (non-condensing)

Operating Temperature

0~50°C

Storage Temperature

-20~60°C

IP rating

Front IP65

Certification
Certification

CE, FCC

IO Ports
USB Port

1 x USB3.0 (Type-A)
3 x USB2.0 (Type-A)

Serial Port

1 x RS232/422/485 (Default RS232)
2 x RS232

1 x RS232 (Optional)

LAN

2 x Giga LAN RJ45 Connector

Video

1 x VGA

Audio

Mic in
Line in
Line out

Expansion Port

2 x mPCIe slot

Indicator

1 x LED Indicator for power
1 x LED Indicator for storage

Brightness Knob

1 x Brightness Adjustment Knob

PS/2

2 x PS/2

mini PCIe

3 x Mini PCIE

Power Input

1 x 12V DC, Din4 pin connector

Control
Button

1 x Power Button
1 x Reset Button

Accessory

100~240V AC to DC Adapter
Power Cord
Driver CD & Manual
VESA screws
Mounting clips

Power
Power Rating

12V DC

Adapter

12V 84W

Parts

R17IB7T-IPM1

17" TFT SXGA LCD PANEL MOUNT TOUCH OPTIONS

Enquire for availability
